Details
The slightly smaller sibling of the KOPE, the DROP is our award-winning, step-thru, dual-battery ebike meticulously-crafted, with a European-inspired design that is best of all, an absolute blast to ride!
Whether you’re bombing around town running errands or heading to the mountains for an epic ride with friends, you’ll go further, faster and with more comfort than anyone else on the road. Period.
The DROP has a traditional drivetrain that uses the SRAM X5 derailleur to change gears and KMC roller chain to transmit power to the rear wheel. This tried and tested design boasts the lightest weight and highest energy efficiency of any design, translating into longer range for those looking to squeeze every last mile from their ebike.
The light-weight, ultimate efficiency, and the ability to repair in case of a roadside emergency make this design popular with sport-minded riders and traditionalists familiar with the components that make up their bike.
RIDE FASTER. RIDE LIGHTER. RIDE MORE EFFICIENTLY.
A wide-range 9-speed 11/34 tooth cassette allows for both superb hill-climbing and high speeds. Perfected over many decades, it remains the most widely-used design in North America and around the world. When well-maintained this design is incredibly reliable and lends itself to roadside repairs if necessary.
The KMC chain is highly corrosion-resistant (even in winter riding conditions), though all chains require regular maintenance depending on the use and riding conditions.
Motor
750W Bafang G340 (BBS02), mid drive motor, 120 nM of torque
Battery
48V, 14 Ah (672 Wh) Samsung lithium ion frame battery
48V, 10.4 Ah (500 Wh) Optional additional lithium battery
Controller
48V, 750W 25 amp
Charger
48V, 2 Amp smart charger
USB Ports
Display: 5V, .5 Amp
Lights
Front: LEZYNE SVTZO MINI 65 (Integrated)
Rear: LEZYNE SVTZO E12 SUPER BRIGHT (Integrated)
Gear Sensor
Bafang SD01 mid-motor gear sensor, waterproof
Dual battery balancer
DOST 42-60V dual battery balancer, waterproof
Display
DOST 3.2" multi-color, backlit LCD with USB charger (DCP-18)
Pedal Assist
Intelligent 5 level pedal assist
Throttle on demand
Brake Calipers
DOST Hydraulic dual-piston
Brake Levers
Cast alumimum comfort grip levers with motor cutoff switch and reach adustments
Brake Pad Material
Metal ceramic compound
Brake Rotors
DOST 180mm front and rear
Chain
KMC Anti-Rust eBike chain
Crank Set
DOST Custom Narrow-Wide Chainring 46T with built in Chain Guide, Lasco Forged Alloy
Derailleur
SRAM X5
Fenders
Included, black plastic front and rear, full coverage
Fork
RST Gila hydraulic lockout and preload adjustment, 100mm travel, 100mm hub width
Frame
6061 aluminum
Freewheel
SPAM 9 speed 11-34T
Gearing
SRAM 1 x 9 speed
Grips
Velo locking, ergonomic
Handlebars
Custom formed aluminum, 31.8mm clamp, 680mm width
Headset
Sealed bearing, 1-1/8" straight steerer tube
Kickstand
Adjustable heavy-duty aluminum with wide plastic foot
Pedals
Wellgo B087 CrMo axle, forged aluminum platform with reflectors, standard 9/16" x 20 TPI threading
Rack
Rear: Integrated, 100 lbs carrying capacity, 16 mm tubing diameter
Rims
Aluminum alloy, double wall, 36H
Saddle
DOST gel, wide saddle with lifting handle
Seat Post
300 mm x 31.6 mm, aluminum alloy
Seat Post Clamp
Quick release
Shifter
SRAM SL X5 Trigger Shifters
Spokes
13-gauge stainless steel, black
Stem
Ergotech, 60º angle adjustment, 100 mm length, 31.8 clamp Ø
Tires
Schwalbe Super Moto X 27.5" x 2.4", puncture resistant, sidewall reflective
Chainguard
DOST chainguard
