Magnum Bikes Navigator X/S Urban Commuter e-bike

Magnum Bikes Navigator X/S Urban Commuter e-bike
  • Color: White with Blue Accent (S)
  • Color: Black with Silver Accent (X)
  • Color: Black with Blue Accent (S)
  • Color: White with Silver Accent (X)
$2,199.00
Color:
Please select options Unavailable
Sorry, this item is currently not available online. Please check back or call 480-275-5818 for availability.

Details

The Magnum Navigator X
A beautifully designed, purpose built electric bike well suited to urban riding or commuting. Step-thru frame for easy mounting and dismounting. Powerful 500W 48V power system with a fully integrated battery.

Can be configured to a Class 1, 2, or 3 E-Bike. Cadence Sensing Pedal Assist, Trigger Throttle, Walk Mode. 25 mph with Pedal Assist, 20 mph with Throttle.

48v 500/750W 12Ah (S-10Ah)

THE BATTERY.

The heart of all Magnum bikes, the long range battery blends in smoothly with the frame for a sleek look. It powers up to 50 miles depending on variables like body and cargo weight, terrain, wind direction, and pedal assist level.

12Ah (10Ah on S model)

50 miles (80 Kilometers) Max Range

6.5 Hours Charge Time

SLEEK, LOW-STEP FRAME

Mount and dismount with ease.

The sleek,low-step frame is easy to mount and dismount, and is made of strong and lightweight aluminum.

Motor Brand

Das-Kit

Motor Type

Rear Gear Hub Motor

Motor Nominal Output

500 Watts

Motor Peak Output

750 Watts

Battery Brand

N/A

Battery Voltage

48V

Battery Ah

12Ah (S-10Ah)

Battery Wh

576Wh

Battery Chemistry

Li-NMC

Battery Charge Time (from empty)

6.5 Hours

Minimum Range

25 Miles (40 Kilometers)

Maximum Range

50 miles (80 Kilometers)

Display Type

Das-Kit C7, Backlit, Monochrome LCD

Display Readouts

Power Output Indicator(6 Bars), Battery Level (6 Bars), Speed, Assist Level (0-6), Odometer, Trip Distance, Trip Time, Battery Voltage

Display Accessories

Drive Mode

Cadence Sensing Pedal Assist, Trigger Throttle, Walk Mode

Top Speed

25 mph with Pedal Assist, 20 mph with Throttle

Lights

Integrated Front and Rear Lights

Frame material

Aluminum Alloy

Frame size

17” (43 cm)

Frame Type

Fork Details

SR Suntour NEX ATB 26”

Gearing details

Shimano 8-Speed

Shifter Details

Shimano 8-Speed

Crank

Prowheel, 48T, 165mm

Pedals

Wellgo

Stem

Promax Tool-Free Adjustable

Brakes

Tektro Hydraulic Disc Brakes

Grips

Ergo Brown Faux Leather

Saddle

Selle Royal Brown Freeway

Tire Brand

CST 26 x 2.25

Wheel size

26”

Fenders

Front and Rear Included

Chain

KMC

Seat Tube

17” (43 cm)

Reach

16.5” (42 cm)

Stand Over Height

21” (53 cm)

Virtual Top Tube Length

23.75” (60 cm)

Min Saddle Height

23” (58 cm)

Max Saddle Height

30” (76 cm)

Width

25.75” (65 cm)

Wheelbase

42.75” (108 cm)

Length

69” (175 cm)

Total Weight

59 lbs (26.75 kg)

Battery Weight

8 lbs

Recommended Minimum Rider Height

5’0”

Max Load Capacity

300 lbs. (140 kg)

Part Numbers

Option UPC
White with Blue Accent (S) 745808932725
Black with Silver Accent (X) 745808932473
Black with Blue Accent (S) 745808932718
White with Silver Accent (X) 745808932930
