Magnum Bikes Peak T7 E-MTB Plus

Magnum Bikes Peak T7 E-MTB Plus
  • Color: Grey
  • Color: Blue
  • Color: Forest Green
  • Color: Tan
$2,999.00
Color:
Please select options Unavailable
Sorry, this item is currently not available online. Please check back or call 480-275-5818 for availability.

Details

The Magnum Peak T7
The Peak T7 begins where the road ends! It has a torque pedal assist sensor that combines power from the rider and the motor for the ultimate in smoothness and control. A wide range drive train, robust power system make the Peak T7 an ideal choice for trail riding.

Can be configured to a Class 1, 2, or 3 E-Bike. Up to 28 mph with Pedal Assist, 20 mph with Throttle.

48v 750/1000W 20Ah

THE BATTERY.

Long-range (up to 65 miles) battery for the freedom and power to tackle longer rides

20Ah

65 Miles (105 Kilometers) Max Range

10 Hours Charge Time

TORQUE-SENSING PEDAL ASSIST

Amplify your effort.

The torque-sensing pedal assist feature adds just the right amount of power from the motor to amplify your effort. It feels just like riding a regular bicycle, but with greater ease and comfort.

Motor Brand

Bafang

Motor Type

Rear Hub-Drive

Motor Nominal Output

750 Watts

Motor Peak Output

1000 Watts

Battery Brand

Samsung Cells

Battery Voltage

48V

Battery Ah

20Ah

Battery Wh

960Wh

Battery Chemistry

Li-NMC

Battery Charge Time (from empty)

10 Hours

Minimum Range

35 Miles (56 Kilometers)

Maximum Range

65 Miles (105 Kilometers)

Display Type

Magnum Branded VeloFox, 8 x 7 cm. Display Screen, Backlit Monochrome LCD

Display Readouts

Battery Level, Assist Level, Current Speed, Power Output, Trip Distance, Odometer, Range, Trip Time

Display Accessories

Drive Mode

Torque Sensor Pedal Assist, Thumb Throttle, Walk Mode

Top Speed

Up to 28 mph with Pedal Assist, 20 mph with Throttle

Lights

Front light controlled from the display. Rear light brake activated. Front Light: 40 lux, Rear Light: 20 lux (Rear light not included)

Frame material

Aluminum Alloy

Frame size

19” (48 cm)

Frame Type

Fork Details

XCM34-Boost

Gearing details

A11-X 11-Speed

Shifter Details

A11-X 11-Speed

Crank

Aluminum Alloy, 42T, 170mm

Pedals

Wellgo

Stem

Magnum 60mm

Brakes

Logan Hydraulic Disc Brakes

Grips

Black

Saddle

Selle Royal Essenza+

Tire Brand

CST Patrol 27.5 x 2.8

Wheel size

27.5”

Fenders

Front and Rear Included

Chain

KMC 11-Speed

Seat Tube

19” (48 cm)

Reach

14.5” (37 cm)

Stand Over Height

31” (78.5 cm)

Virtual Top Tube Length

23.25” (59 cm)

Min Saddle Height

22” (56 cm)

Max Saddle Height

31” (78.5 cm)

Width

28.75” (73 cm)

Wheelbase

45.75” (116 cm)

Length

74” (188 cm)

Total Weight

66 lbs. (30 kg)

Battery Weight

9 lbs. (4 kg)

Recommended Minimum Rider Height

5’6”

Max Load Capacity

330 lbs. (150 kg)

Part Numbers

Option UPC
Grey 789554756242
Blue 789554756228
Forest Green 789554756235
Tan 789554756259
