Magnum Bikes Premium 3 Folding e-bike
Details
Motor Brand
Bafang
Motor Type
Geared Rear Hub
Motor Nominal Output
500 Watts
Motor Peak Output
750 Watts
Battery Brand
N/A
Battery Voltage
48V
Battery Ah
15Ah
Battery Wh
720Wh
Battery Chemistry
Li-NMC
Battery Charge Time (from empty)
7.5 Hours
Minimum Range
30 Miles (48 Kilometers)
Maximum Range
50 miles (80 Kilometers)
Display Type
Magnum Branded VeloFox, 3.5" Diagonal, Fixed, Monochrome, Backlit LCD
Display Readouts
Battery Level, Assist Level, Current Speed, Power Output, Trip Distance, Odometer, Range, Trip Time
Display Accessories
Drive Mode
Cadence Sensing Pedal Assist, Thumb Throttle (Sealed 12 Magnet Cadence Sensor)
Top Speed
Up to 25 mph (40 km) with pedal assist, up to 20 mph with throttle only
Lights
Integrated Front Light w/Horn (20 Lux), Integrated Rear Light (20 Lux)
Seat Tube
15" (42 cm)Reach
17" (47.5 cm)Stand Over Height
15.75" (40 cm)Virtual Top Tube Length
24.5" (62 cm)Min Saddle Height
21.75" (55 cm)Max Saddle Height
31.5" (80 cm)Width
25.5" (65 cm)Wheelbase
47" (119 cm)Length
68" (173 cm)Total Weight
62.25 lbs. (28.25 kg)Battery Weight
11 lbs. (5 kg)Recommended Minimum Rider Height
5'0"Frame material
Aluminum AlloyFrame size
16.75" (42.5 cm)Frame Type
Fork Details
Coil Spring Suspension w/LockoutGearing details
Shimano 7 Speed (14-28t Freewheel)Shifter Details
Shimano 7 SpeedCrank
Alloy, 52t, 170mmPedals
Folding PlatformStem
Folding TelescopicBrakes
Hydraulic Disc BrakesGrips
Ergonomic Faux LeatherSaddle
Padded Saddle w/SuspensionTire Brand
20 x 3.0Wheel size
20"Fenders
Front and Rear IncludedChain
KMCMotor Peak Output
750 WattsBattery Brand
N/ABattery Voltage
48VBattery Ah
15AhBattery Wh
720WhBattery Chemistry
Li-NMCBattery Charge Time (from empty)
7.5 HoursMinimum Range
30 Miles (48 Kilometers)Maximum Range
50 miles (80 Kilometers)Display Type
Magnum Branded VeloFox, 3.5" Diagonal, Fixed, Monochrome, Backlit LCDDisplay Readouts
Battery Level, Assist Level, Current Speed, Power Output, Trip Distance, Odometer, Range, Trip TimeDisplay Accessories
Drive Mode
Cadence Sensing Pedal Assist, Thumb Throttle (Sealed 12 Magnet Cadence Sensor)Top Speed
Up to 25 mph (40 km) with pedal assist, up to 20 mph with throttle onlyLights
Integrated Front Light w/Horn (20 Lux), Integrated Rear Light (20 Lux)Videos
