Masi Evoluzione 105
Details
Built around our MC-X TeXtreme spread-tow carbon fiber frame and fork, the Evo 105 melds race-winning stiffness and handling with in-saddle compliance. For those riders seeking out an alternative to disc brakes, the Evo 105 features direct-mount Shimano 105 brakes and Brev. M components, making it the perfect choice for the budget-minded racer.
- Evoluzione Frameset with race-tuned MC-X TeXtreme carbon, 1.125 - 1.5" tapered head tube, BB86 bottom bracket, mechanical or electronic shifting compatible, internal routing, direct-mount brakes, and replaceable derailleur hanger
- Evoluzione Fork with race-tuned MC-X TeXtreme carbon, tapered carbon steer tube, direct-mount brakes, and carbon dropouts
- Shimano 105 R7000 component group
- Comfort matched Brev. M carbon seat post
- Praxis Works Alba M30 52/36T crankset w/Enduro M30 bearings
- Kenda Valkrie Pro Tubeless Ready 700x25c tires
Specs
| Frame | Evoluzione | race-tuned MC-X TeXtreme carbon | 1.125 - 1.5" tapered head tube | BB86 | Di2 compatible | internal routing | replaceable derailleur hanger | carbon dropouts |
|---|---|
| Fork | Evoluzione | race-tuned MC-X TeXtreme carbon | 1.5" tapered carbon steer tube | carbon dropouts |
| Hubs | Brev M. Race Alloy | QR | 20/24H |
| Tires | Kenda Valkyrie Pro | 700 x 25c | Tubeless ready |
| Bottom Bracket | Praxis Works M30 | BB86 | Enduro bearings |
| Crankset | Praxis Works Alba M30-X | 52/36T chainring | 47 - 51cm: 170mm, 54 - 56cm: 172.5mm, 58 - 61cm: 175mm |
| Shifters | Shimano 105 ST-R7000 |
| Front Derailleur | Shimano 105 FD-R7000 braze-on |
| Rear Derailleur | Shimano 105 RD-R7000SS |
| Cassette/Freewheel | Shimano 105 CS-R7000 | 11-spd | 11-28T |
| Chain | KMC X11 |
| Brakes | Shimano 105 BR-R7010 Direct Mount |
| Brake Levers | Shimano 105 ST-R7000 |
| Handlebars | Brev M. compact alloy race bend | 31.8mm | 125mm drop | 75mm reach | 47-51cm: 40cm, 54-56cm: 42cm, 58-61cm: 44cm |
| Tape/Grips | Masi Gripper Silicone Gel |
| Stem | Brev M. Race | 3D forged alloy | -7° drop | 47cm: 90mm, 51-54cm: 100mm, 56-58cm: 110mm, 61cm: 120mm |
| Headset | Masi by Token 1.5" tapered | Sealed bearing |
| Seatpost | Brev M. Carbon | 27.2mm x 300mm |10mm offset |
| Saddle | Selle Italia Road X short saddle |
| Pedals | Sold separately |
* Subject to change without notice.
