Himiway Cobra Fat-Tire E-MTB Full-Susp

Himiway Cobra Fat-Tire E-MTB Full-Susp
Please select options Unavailable
Sorry, this item is currently not available online. Please check back or call 480-275-5818 for availability.


The four-bar linkage represents a four-sided polygon: the chain stay, seat stay, rocker, and seat tube. These specialize in absorbing both rear-upward force and vibrations while the coil suspension ensures front stability. Both suspensions duly guarantee your safety in toughest riding conditions, and Himiway Cobra is the first e-bike which has this four-bar linkage suspension technology in the U.S. market.

Battery 48V 20Ah Samsung/LG lithium battery
Range 60-80miles
Hub Motor 750W brushless gear hub motor
Total Payload Capacity 400 lbs
Recommended Rider Heights 5'3" ~ 6'4"
Charger US standard 3.0 A smart charger
Controller 48V/22A
Display LCD display with USB charging
Weight 88lbs
Pedal Assist Intelligent 0~5 level pedal assist

Tires 26" x 4.8" CST fat tires
Brake lever Aluminum alloy comfort grip levers with motor cutoff switch
Rear Light Battery powered bike light
Freewheel Shimano 7 speed gear shift system
Brake180MM Hydraulic Brakes
Chain KMC chain
Stem Promax MA-400 SSABK
Crank 170mm forged alloy
Gearing Shimano- 14-28T BROWN/BK
Front Fork Alloy front suspension fork with lockout and adjustment
Throttle Half twist throttle
Pedal Alloy pedal with reflectors
Bike Frame 6061 Aluminum frame
Front Light 48V LED light
Saddle SR saddle
Seat Post Diameter 30.9mm length 300mm
Kickstand Heavy duty aluminum
Spokes 13 Gauge on the front / 12 Gauge on the back

Himiway has the right without notice to the consumer to substitute components of at least equal quality for advertised Himiway ebike components in the event of the unavailability of such advertised components
